Request For Our Latest Prices on Stainless Steel 17-4 PH Stud Bolts in Hamilton, New Zealand!
Aria Fasteners, based in Hamilton, New Zealand, stands out as a top-notch manufacturer and supplier of high-performance stainless steel fastening solutions, specifically designed for tough industrial applications. Their Stainless Steel 17-4 PH Stud Bolts are celebrated for their remarkable strength, resistance to corrosion, and impressive durability. Crafted with cutting-edge manufacturing techniques and rigorous quality control, these stud bolts are built to comply with strict international standards. Aria Fasteners caters to a variety of industries, including aerospace, marine, petrochemical, automotive, and general engineering, providing fastening products that guarantee structural integrity, safety, and reliable performance even in the most challenging conditions.
The Stainless Steel 17-4 PH Stud Bolts are made from a precipitation-hardening stainless steel alloy that includes 15–17.5% chromium, 3–5% nickel, 3–5% copper, along with trace amounts of niobium. This unique blend gives the material an exceptional mix of hardness, strength, and corrosion resistance. After undergoing the right heat treatment, 17-4 PH can achieve tensile strengths of up to 1,300 MPa and yield strengths around 1,100 MPa, all while maintaining good toughness. The alloy also boasts excellent dimensional stability and stress resistance, making it perfect for high-load and corrosive environments.
| Specifications | ASTM A 193 / ASME SA 193 |
|---|---|
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 | 15.00-17.50 | 3.00-5.00 | Bal | 1.0 max | 3.0-5.0 | 0.40 max | 0.03 max | 1.0 max |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless steel 17-4 PH stud bolts are widely used in complex environments due to their exceptional strength and durability. It is commonly used in aerospace applications including aircraft and spacecraft, where high-end technology is critical. In industrial machinery and automobiles, these screws are prized for their ability to withstand high stresses and fatigue. In addition, they are used in the chemical industry and marine environment due to their excellent corrosion resistance. Their stability at high temperature high-presure applications across various industries.
These stud bolts find their place in applications where top-notch mechanical strength and corrosion resistance are crucial. They’re frequently used in aerospace components, marine structures, chemical processing systems, and offshore equipment, thanks to their ability to endure harsh environmental conditions. Moreover, they are vital in oil and gas installations, power generation systems, heavy machinery, and high-precision engineering assemblies. With Stainless Steel 17-4 PH Stud Bolts, you can count on reliable fastening performance that ensures durability, safety, and long-lasting structural integrity.
Aria Fasteners is a leading manufacturer and supplier of high-quality fasteners in Hamilton, New Zealand, with over 8 years of experience serving global industries.
